High Quality Compressor Lubricant - ACPL-VCP DC Diffusion pump silicone oil – Jiongcheng Detail:

Product Introduction

ACPL-VCP DC is a single-component silicone oil specially designed for use in ultra-high vacuum diffusion pumps. It has high thermal oxidation stability, small viscosity-temperature coefficient, narrow boiling point range, and steep vapor pressure curve (a little temperature change, a large vapor pressure change), low steam pressure at room temperature, low freezing point, coupled with chemical inertness, non-toxic, odorless, and non-corrosive. Therefore, it can be used for a long time under 25CTC, in a vacuum environment, allowing higher temperature use.

ACPL-VCP DC product performance and advantages
● Reduce the running time.
● Single-component silicone oil takes much shorter time to reach the maximum vacuum degree than with multi-component silicone oil, and it is quickly evacuated.
● Minimal reflux, the vapor pressure of the diffusion pump silicone oil is extremely low, so that it is not necessary for many applications or existing traps to refrigerate.
● Longer service life.
● The thermal and chemical stability of silicone oil allows long-term operation without deterioration and pollution.
● The cleaning system needs less maintenance.
● Fast cycle, reducing downtime, and less need to change oil.

ACPL-VCP DC Diffusion pump silicone oil06

Purpose

ACPL-VCP DC diffusion pump silicone oil can be used as ultra-high vacuum diffusion pump oil in electronics, metallurgy, instrumentation and other industries.
It can be used as high temperature heat carrier and transfer fluid in the instrument.
It can be used as the working fluid of the ultra-high diffusion pump required by the electronics, aerospace, nuclear industry and other industries.

Project name

ACPL-VCP DC704

ACPL-VCP DC705

Test metod

Kinematic viscosity (40℃), mm2/s

38-42

165-185

GB/T265

Refractive index 25℃

1.550-1.560

1.5765-1.5787

GB/T614

Specific gravity d25 25

1.060-1.070

1.090-1.100

GB/T1884

Flash point (opening), ℃≥

210

243

GB/T3536

Density(25℃) g/cm3

1.060-1.070

1.060-1.070

Saturated vapor pressure, Kpa <

5.0×10-9

5.0×10-9

SH/T0293

Ultimate vacuum degree, (Kpa), 4

1.0×10-8

1.0×10-8

SH/T0294
